| Green Mode |
|
|
|
| DoE Level VI, ErP Stage 2, CoC Tier 2 |
| No Load Power Consumption Less Than 0.15W |
| Model | O/P Voltage | O/P Current A | Watt |
| AC120V8.00-CS* | 12 | 8.00 | 96 |
| AC150V8.00-CS* | 15 | 8.00 | 120 |
| AC160V7.50-CS* | 16 | 7.50 | 120 |
| AC185V6.50-CS* | 18.5 | 6.50 | 120 |
| AC190V6.30-CS* | 19 | 6.30 | 120 |
| AC195V6.15-CS* | 19.5 | 6.15 | 120 |
| AC200V6.00-CS* | 20 | 6.00 | 120 |
| AC240V5.00-CS* | 24 | 5.00 | 120 |
| AC300V4.00-CS* | 30 | 4.00 | 120 |
| AC360V3.30-CS* | 36 | 3.30 | 120 |
| AC480V2.50-CS* | 48 | 2.50 | 120 |
|
|
|
|
| (*) are blank, or 3 or 4, means C8, C6, C14 Inlet |
| Input |
| Voltage | 100-240 VAC |
| Line Frequency | 50-60Hz |
| Current | 2.0A Max. |
| Protection | Internal Primary Current Fuse |
| Configuration | IEC60320/C6,C14 |
| Output |
| Load Regulation | ± 5%(Typical) |
| Ripple | 2% Vp-p Max. for Output Voltage @ Full Load |
| Transient Response | 0.5mS for 50% Load Change Typical |
| Holdup time | 10mS @ Full Load |
| Protection | Short Circuit Protection/ Over Voltage Protection/ Over Current |
| Protection/ Over Temperature Protection |
| DC Cord | 18AWG / 16AWG / 14AWG |
| Ferrite Core | NO |
| Safety Approvalsl |
| CB / ETL / cETL / FCC / GS/ CE |
|
|
| Electrical |
| Topology | Switching Flyback |
| Dielectric Withstand | 3,000 VAC Primary - Secondary |
| Leakage Current | 3.5mA @ 3Pin |
| Efficiency | DoE Level VI, Energy Star, ErP Stage 2, NRCan & GEMS Level VI Certified |
| EMI Conduction&Radiation | Compliance to EN55032 Class B |
| Harmonic Current | Compliance to EN61000-3-2,3 |
| EMS Immunity | Compliance to EN61000-4-2,3,4,5,6,8,11 |
| MTBF | 300,000 Calculated Hours at 25°C, by Telcordia SR-332 |
| Environmental |
| Operaturing Temperature | 0 to +40°C |
| Storage Temperature | -20 to +80°C |
| Relative Humidity | Operating: 20 to 80% RH |
| Storage: 10 to 90% RH |
| Cooling | Natural Convection Cooling |
| Mechanical |
| Case Dimension | L 169 x W65 x H43 (mm) |
| Weight | 590g (Ref.) |
